920i® Programmable Weight Indicator and Controller

Trade Aproved (1711) The 920i® weight indicator and process controller blends revolutionary user interfaces, total flexibility and processing performance with the simplicity of a basic weight indicator. A crisp, highly customizable LCD graphical display, programmable softkeys and industry recognized electronics are surrounded by a virtually indestructible enclosure to create one of the industry’s most trusted weight indicators and process controllers.

Description

Standard Features

  • LCD display, (W x H) 4.6 in x 3.4 in
  • Selectable character sizes from 0.25 in to 1.2 in
  • 60 configurable operator prompts
  • Display up to four scale channels per screen with required Legal for Trade information
  • 32 scale accumulators
  • Five softkeys with 10 user-defined, 14 preset functions per screen
  • Ten programmable display screens
  • Millivolt calibration, five-point linearization and geographical calibration
  • NEMA Type 4X/IP66 stainless steel enclosure
  • Selectable A/D measurement rate up to 960/second
  • 100 setpoints, 30 configurable setpoint types
  • Two slots for option cards
  • 1,000-ID truck register for in/out weighing
  • 64K user on-board NV RAM
  • User programmable 128K flash memory
  • Reflash memory to upgrade firmware
  • Power for 16 350-ohm load cells per A/D board
  • Local-remote indicators
  • Multi range/interval
  • Alibi™ storage
  • Audit trail tracking
  • Peak hold
  • Rate of change

USB Standard Features

  • USB interface card on Port 2
  • The USB card is supported on Rev L CPU boards or later
  • The 920i for USB interface requires firmware version 5.0 or higher

Connector Types:

  • Standard Type A: 920i connects to keyboard,
    ASCII font printers and flash drives
  • Standard Type B: 920i connects to PC

USB Interface Functions:

  • Supports weigh mode and configuration mode functions
  • Supports upload of databases and .920 configuration file
  • Supports download of databases, .920 configuration file, iRite, COD file and firmware file
  • Sanity checks for command errors

Flash Drives:

  • Supports USB 2.0
  • Create subdirectories by unit ID and database name
  • Use the root directory for generic files

Optional Washdown Connectors:

  • Sealed receptacle
  • Connectors – cables
  • USB cover – flash drive and receptacle
