iDimension® Plus Static Dimensioning System⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀

iDimension® Plus Static Dimensioning System⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀

When it comes to calculating dimensions of boxes, flats, polybags and more, Rice Lake’s iDimension Plus is the fastest static tabletop solution on the market. The iDimension Plus helps prevent revenue loss by providing accurate dimensional weight calculations required by parcel and postal carriers. Put the iDimension Plus to use right away—simply open and assemble to instantly display dimensions.


iDimension® Plus Static Dimensioning System

  • Easy to assemble with limited operator training required, up and running in as few as 30 minutes


  • Displays dimensions in less than 0.2 seconds


  • Requires virtually no special alignment or special handling while placing a package to increase throughput with adjustable scan zone and area of interest
  • Includes 7 in (178 mm) USB touchscreen monitor: Displays dimensions, image, status and weight (if scale is directly attached) Initial setup and configuration wizard
  • Access to operator controls and functions
  • Dimensions parcels at 0.2 in (5 mm) Legal for Trade accuracy
  • Dimensions irregular shaped packages and polybags to 0.5 in NTEP Legal for Trade accuracy using automatic recognition
  • Legal for Trade measurements do not determine the minimum and maximum measurement capabilities available


  • Includes low resolution, overhead color image of every item, available in .bmp or .jpg format through XLM API integration
  • High resolution color image, 2880 x 2160 pixels, available from iDimension Plus 4K


  • Optional powered USB Hub for use of more than one peripheral
  • Optional USB barcode scanner with keyboard wedge emulation will manually trigger dimensioning and add barcode text data into web service API
  • Rice Lake BenchPro shipping/postal scales and compatible indicators
