WWSERF: 750 x 450mm Wireless Wheel Weighing Pads

Wireless pads designed for creating wheel and axle vehicle weighing stations, avoiding the hassle of connecting cables between the pads and the indicator. Ideal for weighing larger vehicles (vans, trucks, tankers, trucks etc..); particularly accurate and sturdy, with attention to details.

Description

Features

  • Pad dimensions:
    – weighing surface: 750 x 450 x 58 mm.
    – total (with wheels): 805 x 561 x 58 mm.
  • Weight approximately 28kg.
  • Transit area: 603 x 450 mm.
  • Very handy.
  • Sturdy structure, made in special aluminium, which guarantees lightness and makes these pads suitable also for harsh working conditions.
  • Stainless steel load cells.
  • Overall IP68 protection degree.
  • Sturdy built-in weight indicator, protected thanks to an IP68 hermetic box.
  • Built-in radio module for weight transmission to a remote indicator or external device. Max. functioning distance: 50m.
  • Integrated wheels for easy transport and positioning.
  • Power supply: internal rechargeable battery (about 40 h battery life), kept in hermetic box, and charger included (to not use as power adaptor).
  • Special vulcanised nonslip rubber applied under the pad, for good grip on all types of surfaces.
  • The WWS pads are patented; the number is 1.342.302.
  • Availables in legal for trade approved version.
  • Availables in high resolution version.

WWS-R: Additional on/off ramps

Integrated folding ramps, useful to facilitate the boarding and the alighting of vehicles with small diameter wheels or moved with the engine off.

In the example, an application with 2 WWS-R ramps.
