TLKWF – WiFi Digital Weight Transmitter

WiFi weight transmitter into IP65 case (on request IP67 version) with backlit LCD display, 38×16 mm, two-line by eightdigit (5 mm height). Four-key keypad for the system calibration. Six indicator LED. 3 PG9 cable glands. Dimensions: 170 x 80 x 65 mm (centre distance 120×60 mm).

Category: Tags: ,



  • Wifi module for wireless connection via integrated web server (for remote management to PC, smartphone, tablet, etc.) or via Modbus RTU/Laumas ASCII protocol.
  • RS232 and RS485 ports (Modbus RTU/Laumas ASCII protocol)
  • Connectable to others TLKWF devices and W series Laumas instruments with OPZW1RADIO optional
  • 2 digital inputs, 4 relay digital outputs
  • 1 load cell input
  • Wall mounting
  • A/D converter – 24bit (16000000 points) 4.8 kHz
  • Display range 999999

Optional features:

  • IP67 box version
  • Rechargeable internal/external battery
